Sine-wave Filter for Frequency Converters
OF7S1-S-AN-25-170A-070-TX-E20
Air-cooled, passive, 200-500 V AC
170 A, 70 Hz
Thermal Switch: None
IP20/Open Type
Sine-Wave Filter IP20 size 08
Other options according to Model code
The sine-wave filter provides a sinusoidal phase-to-phase motor supply voltage. The filter reduces motor insulation str.
| Gross weight | 133 kg |
| Net weight | 112.5 kg |
| Volume | 336 l |
| EAN | 5714853340934 |
| Product View (Switch) | GLBL | Global (Standard) |
| Product series | OF7S1 | Sine-wave Filter |
| Product target | -S | Frequency Converters |
| Cooling method | -AN | Air-cooled, passive |
| Voltage class | -25 | 200-500 V AC |
| Current rating | -170A | 170 A |
| Nominal frequency | -070 | 70 Hz |
| Thermal protection | -TX | None |
| Protection rating | -E20 | IP20/Open Type |
| Frame designation | S1A08 | Sine-Wave Filter IP20 size 08 |
| Typecode Part 1 | OF7S1-S-AN-25-170A-070-TX-E20 | |
| Salescode part 1 | OF7S1-S-AN-25-170A-070-TX-E20 | |
| Product Catalog | NO_VIEW | NO VIEW |
| Calculated Gross Weight [kg] | 133 | |
| Calculated Net Weight [kg] | 112.5 | |
| Modelcode01 | OF7S1-S-AN-25-170A-070-TX-E20 | |
