Frequency converter
FC-202P7K5T4P66H1TGCXOXSXXXXALBPCXXXXD0
VLT® AQUA Drive FC-202
(P7K5) 7.5 KW / 10 HP, Three phase
380 - 480 VAC, (P66) IP66 / NEMA 4X Backplate
(H1) RFI Class A1/B (C1)
Safe Stop
Graphical Loc. Cont. Panel
Coated PCB, No Mains Option
Latest release std. SW.
PROFINET MCA 120, MCB-105 Relay Card
No C1 option, MCB-107 24V DC backup
Frame: A5
Other options according to Model code
Danfoss VLT® AQUA Drive is dedicated to water and wastewater applications. With a wide range of powerful sta.
| Gross weight | 14.5 kg |
| Net weight | 14.2 kg |
| Volume | 52.36 l |
| EAN | 5714853034864 |
| Product View (Switch) | GLBL | Global (Standard) |
| Product Group | FC- | VLT® AQUA Drive FC- |
| Series | 202 | 202 |
| Power Rating | P7K5 | (P7K5) 7.5 KW / 10 HP |
| Phase | T | Three phase |
| Mains Voltage | 4 | 380 - 480 VAC |
| Enclosure | P66 | (P66) IP66 / NEMA 4X Backplate |
| RFI Filter | H1 | (H1) RFI Class A1/B (C1) |
| Brake - Safe Stop | T | Safe Stop |
| LCP | G | Graphical Loc. Cont. Panel |
| Coating PCB | C | Coated PCB |
| Mains Option | X | No Mains Option |
| Adaptation A | O | Metric thread cable entry |
| Adaptation B | X | No adaptation |
| Software Release | SXXX | Latest release std. SW. |
| Software Language Pack | X | Standard Language Pack |
| A Option | AL | PROFINET MCA 120 |
| B Option | BP | MCB-105 Relay Card |
| C0 Option MCO | CX | No C0 option |
| C1 Option | X | No C1 option |
| C Option Software | XX | No software option |
| D Option | D0 | MCB-107 24V DC backup |
| Frame Size | A5 | A5 |
| Typecode Part 1 | FC-202P7K5T4P66H1TGC | |
| Typecode Part 2 | XOXSXXXXALBPCXXXXD0 | |
| Product Catalog | GLBL | Global (Standard) |
| Height [mm] | 420,0 | |
| Width w/ no C options [mm] | 242,0 | |
| Depth [mm] | 200,0 | |
| Depth with Option A/B [mm] | 200,0 | |
| Power Loss NO [W] | 225 | |
| Power Loss NO [W] | 225 | |
| Power Loss HO [W] | 225 | |
| Power Loss HO [W] | 225 | |
| Calculated Gross Weight [kg] | 15.3 | |
| Calculated Net Weight [kg] | 15 | |
| Material Gross Weight | 14.5 | |
| Material Net Weight | 14.2 | |
| Vendor | ERR01 | Cannot Determine Vendor |
| Recommended Factory | ERR01 | Cannot Determine Vendor |
| Modelcode01 | FC-202P7K5T4P66H1TGC | |
| Modelcode02 | XOXSXXXXALBPCXXXXD0 |
