Frequency converter
FC-202P2K2T6E20HXXNCXXXSXXXXANBXCX5XXDX
VLT® AQUA Drive FC-202
(P2K2) 2.2 KW / 3.0 HP, Three phase
525 - 600 VAC, (E20) IP20 / Chassis
No RFI Filter
No brake chopper
Numerical Loc. Cont. Panel
Coated PCB, No Mains Option
Latest release std. SW.
EtherNet/IP MCA 121, No B Option
MCO-102 Ad Cascade Control, No D option
Frame: A3
Other options according to Model code
Danfoss VLT® AQUA Drive is dedicated to water and wastewater applications. With a wide range of powerful sta.
| Gross weight | 6.8 kg |
| Net weight | 6.5 kg |
| Volume | 0 l |
| EAN | 5715253306995 |
| Product View (Switch) | NAMC | North America (Regional) |
| Product Group | FC- | VLT® AQUA Drive FC- |
| Series | 202 | 202 |
| Power Rating | P2K2 | (P2K2) 2.2 KW / 3.0 HP |
| Phase | T | Three phase |
| Mains Voltage | 6 | 525 - 600 VAC |
| Enclosure | E20 | (E20) IP20 / Chassis |
| RFI Filter | HX | No RFI Filter |
| Brake - Safe Stop | X | No brake chopper |
| LCP | N | Numerical Loc. Cont. Panel |
| Coating PCB | C | Coated PCB |
| Mains Option | X | No Mains Option |
| Adaptation A | X | Standard Cable Entries |
| Adaptation B | X | No adaptation |
| Software Release | SXXX | Latest release std. SW. |
| Software Language Pack | X | Standard Language Pack |
| A Option | AN | EtherNet/IP MCA 121 |
| B Option | BX | No B Option |
| C0 Option MCO | CX | No C0 option |
| C1 Option | 5 | MCO-102 Ad Cascade Control |
| C Option Software | XX | No software option |
| D Option | DX | No D option |
| Frame Size | A3 | A3 |
| Typecode Part 1 | FC-202P2K2T6E20HXXNC | |
| Typecode Part 2 | XXXSXXXXANBXCX5XXDX | |
| Product Catalog | NAMC | North America (Regional) |
| Power 150% (HO) [KW] | 2.2 | |
| Power 110% (NO) [KW] | 2.2 | |
| Height [mm] | 268,0 | |
| Width w/ no C options [mm] | 130,0 | |
| Depth [mm] | 205,0 | |
| Depth with Option A/B [mm] | 220,0 | |
| kVA | 3.88 | |
| Power Loss NO [W] | 92 | |
| Power Loss NO [W] | 92 | |
| Power Loss HO [W] | 92 | |
| Power Loss HO [W] | 92 | |
| Continuous Current (NO) [A] | 4.1 | |
| Intermittent Current (NO) [A] | 4.51 | |
| Continuous Current (NO) [A] | 3.9 | |
| Intermittent Current (NO) [A] | 4.29 | |
| Continuous Current (HO) [A] | 4.1 | |
| Intermittent Current (HO) [A] | 6.15 | |
| Continuous Current (HO) [A] | 3.9 | |
| Intermittent Current (HO) [A] | 5.85 | |
| Calculated Gross Weight [kg] | 6.8 | |
| Calculated Net Weight [kg] | 6.5 | |
| Plant from Orderline | F605 | |
| Vendor | ERR01 | Cannot Determine Vendor |
| Recommended Factory | ERR01 | Cannot Determine Vendor |
| Modelcode01 | FC-202P2K2T6E20HXXNC | |
| Modelcode02 | XXXSXXXXANBXCX5XXDX |
