Frequency converter
FC-202P1K1S2E20H2XGXXXXLX1XXAXB5CXXXXD1
VLT® AQUA Drive FC-202
(P1K1) 1.1 KW / 1.5 HP, Single phase
200 - 240 VAC, (E20) IP20 / Chassis
RFI Filter
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB, No Mains Option
Condition Based Monitoring CBM
No A Option, MCB-115 Programmable I/O
No C1 option, MCB-117 Real time clock option
Frame: A3
Other options according to Model code
Danfoss VLT® AQUA Drive is dedicated to water and wastewater applications. With a wide range of powerful sta.
| Gross weight | 6.9 kg |
| Net weight | 6.6 kg |
| Volume | 22.04 l |
| EAN | 5715253377247 |
| Product View (Switch) | GLBL | Global (Standard) |
| Product Group | FC- | VLT® AQUA Drive FC- |
| Series | 202 | 202 |
| Power Rating | P1K1 | (P1K1) 1.1 KW / 1.5 HP |
| Phase | S | Single phase |
| Mains Voltage | 2 | 200 - 240 VAC |
| Enclosure | E20 | (E20) IP20 / Chassis |
| RFI Filter | H2 | RFI Filter |
| Brake - Safe Stop | X | No brake chopper |
| LCP | G | Graphical Loc. Cont. Panel |
| Coating PCB | X | Not coated PCB |
| Mains Option | X | No Mains Option |
| Adaptation A | X | Standard Cable Entries |
| Adaptation B | X | No adaptation |
| Software Release | LX1X | Condition Based Monitoring CBM |
| Software Language Pack | X | Standard Language Pack |
| A Option | AX | No A Option |
| B Option | B5 | MCB-115 Programmable I/O |
| C0 Option MCO | CX | No C0 option |
| C1 Option | X | No C1 option |
| C Option Software | XX | No software option |
| D Option | D1 | MCB-117 Real time clock option |
| Frame Size | A3 | A3 |
| Typecode Part 1 | FC-202P1K1S2E20H2XGX | |
| Typecode Part 2 | XXXLX1XXAXB5CXXXXD1 | |
| Product Catalog | GLBL | Global (Standard) |
| Power 110% (NO) [KW] | 1.1 | |
| Height [mm] | 268,0 | |
| Width w/ no C options [mm] | 130,0 | |
| Depth [mm] | 205,0 | |
| Depth with Option A/B [mm] | 220,0 | |
| kVA | 2.38 | |
| Power Loss NO [W] | 44 | |
| Continuous Current (NO) [A] | 6.6 | |
| Intermittent Current (NO) [A] | 7.26 | |
| Calculated Gross Weight [kg] | 6.9 | |
| Calculated Net Weight [kg] | 6.6 | |
| Plant from Orderline | B901 | |
| Vendor | ERR01 | Cannot Determine Vendor |
| Recommended Factory | ERR01 | Cannot Determine Vendor |
| Modelcode01 | FC-202P1K1S2E20H2XGX | |
| Modelcode02 | XXXLX1XXAXB5CXXXXD1 |
