Frequency converter
FC-202P5K5T7E20H8UGCXXXSXXXXAXBXCXXXXDX
VLT® AQUA Drive FC-202
(P5K5) 5.5 KW / 7.5 HP, Three phase
525 - 690 VAC *, (E20) IP20 / Chassis
RFI C2
Brake chopper + Safe stop
Graphical Loc. Cont. Panel
Coated PCB, No Mains Option
Latest release std. SW.
No A Option, No B Option
No C1 option, No D option
Frame: A3
Other options according to Model code
Danfoss VLT® AQUA Drive is dedicated to water and wastewater applications. With a wide range of powerful sta.
| Gross weight | 7.5 kg |
| Net weight | 7.2 kg |
| Volume | 22.04 l |
| EAN | 5715253393254 |
| Product View (Switch) | GLBL | Global (Standard) |
| Product Group | FC- | VLT® AQUA Drive FC- |
| Series | 202 | 202 |
| Power Rating | P5K5 | (P5K5) 5.5 KW / 7.5 HP |
| Phase | T | Three phase |
| Mains Voltage | 7 | 525 - 690 VAC * |
| Possible rating issue | WARN01 | Possible Rating Issue: |
| Enclosure | E20 | (E20) IP20 / Chassis |
| RFI Filter | H8 | RFI C2 |
| Brake - Safe Stop | U | Brake chopper + Safe stop |
| LCP | G | Graphical Loc. Cont. Panel |
| Coating PCB | C | Coated PCB |
| Mains Option | X | No Mains Option |
| Adaptation A | X | Standard Cable Entries |
| Adaptation B | X | No adaptation |
| Software Release | SXXX | Latest release std. SW. |
| Software Language Pack | X | Standard Language Pack |
| A Option | AX | No A Option |
| B Option | BX | No B Option |
| C0 Option MCO | CX | No C0 option |
| C1 Option | X | No C1 option |
| C Option Software | XX | No software option |
| D Option | DX | No D option |
| Frame Size | A3 | A3 |
| Typecode Part 1 | FC-202P5K5T7E20H8UGC | |
| Typecode Part 2 | XXXSXXXXAXBXCXXXXDX | |
| Product Catalog | GLBL | Global (Standard) |
| Power 150% (HO) [KW] | 5.5 | |
| Power 110% (NO) [KW] | 5.5 | |
| Height [mm] | 268,0 | |
| Width w/ no C options [mm] | 130,0 | |
| Depth [mm] | 205,0 | |
| Depth with Option A/B [mm] | 220,0 | |
| kVA | 8.96 | |
| Power Loss NO [W] | 220 | |
| Power Loss NO [W] | 220 | |
| Power Loss HO [W] | 220 | |
| Power Loss HO [W] | 220 | |
| Continuous Current (NO) [A] | 9 | |
| Intermittent Current (NO) [A] | 9.9 | |
| Continuous Current (NO) [A] | 7.5 | |
| Intermittent Current (NO) [A] | 8.25 | |
| Continuous Current (HO) [A] | 9 | |
| Intermittent Current (HO) [A] | 13.5 | |
| Continuous Current (HO) [A] | 7.5 | |
| Intermittent Current (HO) [A] | 11.2 | |
| Calculated Gross Weight [kg] | 7.5 | |
| Calculated Net Weight [kg] | 7.2 | |
| Plant from Orderline | B901 | |
| Vendor | ERR01 | Cannot Determine Vendor |
| Recommended Factory | ERR01 | Cannot Determine Vendor |
| Modelcode01 | FC-202P5K5T7E20H8UGC | |
| Modelcode02 | XXXSXXXXAXBXCXXXXDX |
