FC-301P5K5T4E20H2XXXXXXSXXXXAXBXCXXXXDX
Frequency converter
FC-301P5K5T4E20H2XXXXXXSXXXXAXBXCXXXXDX
VLT® AutomationDrive FC-301
(P5K5) 5.5 KW / 7.5 HP, Three phase
380 - 480 VAC, (E20) IP20 / Chassis
RFI Filter
No brake chopper
No Loc. Cont. Panel
Not coated PCB, No Mains Option
Latest release std. SW.
No A Option, No B Option
No C1 option, No D option
Frame: A3
Other options according to Model code
Model code:
FC-301P5K5T4E20H2XXXXXXSXXXXAXBXCXXXXDX
The VLT® AutomationDrive represents a single drive concept that controls the entire range of operations from ordinary t.
| Gross weight |
6.45 kg |
| Net weight |
5.86 kg |
| Volume |
29.754 l |
| EAN |
5702427147720 |
Sales restriction control
| Matr grp for sales restriction |
0001 |
No grouping |
VLT® AUTOMATIONDRIVE FC 300 SERIES
| Product View (Switch) |
GLBL |
Global (Standard) |
| Product Group |
FC- |
VLT® AutomationDrive FC- |
| Series |
301 |
301 |
| Power Rating |
P5K5 |
(P5K5) 5.5 KW / 7.5 HP |
| Phase |
T |
Three phase |
| Mains Voltage |
4 |
380 - 480 VAC |
| Enclosure |
E20 |
(E20) IP20 / Chassis |
| RFI Filter |
H2 |
RFI Filter |
| Brake - Safe Stop |
X |
No brake chopper |
| LCP |
X |
No Loc. Cont. Panel |
| Coating PCB |
X |
Not coated PCB |
| Mains Option |
X |
No Mains Option |
| Adaptation A |
X |
Standard Cable Entries |
| Adaptation B |
X |
No adaptation |
| Software Release |
SXXX |
Latest release std. SW. |
| Software Language Pack |
X |
Standard Language Pack |
| A Option |
AX |
No A Option |
| B Option |
BX |
No B Option |
| C0 Option MCO |
CX |
No C0 option |
| C1 Option |
X |
No C1 option |
| C Option Software |
XX |
No software option |
| D Option |
DX |
No D option |
| Frame Size |
A3 |
A3 |
| Typecode Part 1 |
FC-301P5K5T4E20H2XXX |
| Typecode Part 2 |
XXXSXXXXAXBXCXXXXDX |
| Product Catalog |
NO_VIEW |
NO VIEW |
| Power 160% (HO) [KW] |
5.5 |
| Height [mm] |
268,0 |
| Width w/ no C options [mm] |
130,0 |
| Depth [mm] |
205,0 |
| Depth with Option A/B [mm] |
220,0 |
| kVA |
9.01 |
| Power Loss HO [W] |
187 |
| Power Loss HO [W] |
187 |
| Continuous Current (HO) [A] |
13 |
| Intermittent Current (HO) [A] |
20.8 |
| Continuous Current (HO) [A] |
11 |
| Intermittent Current (HO) [A] |
17.6 |
| Calculated Gross Weight [kg] |
6.33 |
| Calculated Net Weight [kg] |
5.8 |
| Material Gross Weight |
6.45 |
| Material Net Weight |
5.86 |
| Vendor |
ERR01 |
Cannot Determine Vendor |
| Modelcode01 |
FC-301P5K5T4E20H2XXX |
| Modelcode02 |
XXXSXXXXAXBXCXXXXDX |
