Frequency converter
FC-202PK37T4E66H3TGXXXXSXXXXAXBXCXXXXDX
VLT® AQUA Drive FC-202
(PK37) 0.37 KW / 0.50 HP, Three phase
380 - 480 VAC, (E66) IP66 / NEMA 4X
(H3) RFI Class A1/B (C1)
Safe Stop
Graphical Loc. Cont. Panel
Not coated PCB, No Mains Option
Latest release std. SW.
No A Option, No B Option
No C1 option, No D option
Frame: A5
Other options according to Model code
Danfoss VLT® AQUA Drive is dedicated to water and wastewater applications. With a wide range of powerful sta.
Gross weight | 12.4 kg |
Net weight | 12.1 kg |
Volume | 52.36 l |
EAN | 5702427812802 |
Product View (Switch) | GLBL | Global (Standard) |
Product Group | FC- | VLT® AQUA Drive FC- |
Series | 202 | 202 |
Power Rating | PK37 | (PK37) 0.37 KW / 0.50 HP |
Phase | T | Three phase |
Mains Voltage | 4 | 380 - 480 VAC |
Enclosure | E66 | (E66) IP66 / NEMA 4X |
RFI Filter | H3 | (H3) RFI Class A1/B (C1) |
Brake - Safe Stop | T | Safe Stop |
LCP | G | Graphical Loc. Cont. Panel |
Coating PCB | X | Not coated PCB |
Mains Option | X | No Mains Option |
Adaptation A | X | Standard Cable Entries |
Adaptation B | X | No adaptation |
Software Release | SXXX | Latest release std. SW. |
Software Language Pack | X | Standard Language Pack |
A Option | AX | No A Option |
B Option | BX | No B Option |
C0 Option MCO | CX | No C0 option |
C1 Option | X | No C1 option |
C Option Software | XX | No software option |
D Option | DX | No D option |
Frame Size | A5 | A5 |
Typecode Part 1 | FC-202PK37T4E66H3TGX | |
Typecode Part 2 | XXXSXXXXAXBXCXXXXDX | |
Product Catalog | GLBL | Global (Standard) |
Power 150% (HO) [KW] | 0.37 | |
Power 110% (NO) [KW] | 0.37 | |
Height [mm] | 420,0 | |
Width w/ no C options [mm] | 242,0 | |
Depth [mm] | 200,0 | |
Depth with Option A/B [mm] | 200,0 | |
kVA | 0.9 | |
Power Loss NO [W] | 35 | |
Power Loss NO [W] | 35 | |
Power Loss HO [W] | 35 | |
Power Loss HO [W] | 35 | |
Continuous Current (NO) [A] | 1.3 | |
Intermittent Current (NO) [A] | 1.43 | |
Continuous Current (NO) [A] | 1.2 | |
Intermittent Current (NO) [A] | 1.32 | |
Continuous Current (HO) [A] | 1.3 | |
Intermittent Current (HO) [A] | 1.95 | |
Continuous Current (HO) [A] | 1.2 | |
Intermittent Current (HO) [A] | 1.8 | |
Calculated Gross Weight [kg] | 13.4 | |
Calculated Net Weight [kg] | 13.1 | |
Material Gross Weight | 12.4 | |
Material Net Weight | 12.1 | |
Vendor | ERR01 | Cannot Determine Vendor |
Recommended Factory | ERR01 | Cannot Determine Vendor |
Modelcode01 | FC-202PK37T4E66H3TGX | |
Modelcode02 | XXXSXXXXAXBXCXXXXDX |
